Features
1. On-demand production efficiently response customer orders.
2. Eliminate mechanical dies cost and warehouse cost.
3. QR code/Bar code scanning, supports jobs change on the fly.
4. Digital work flow streamlines operations.
5. Modular design to meet customers' individual needs.
6. One-time investment, Low maintenance cost.
Application
Specifications
|
Model |
LQ-MD350 |
|
Max cuttng width |
340mm |
|
Max cuttng length |
Unlimited |
|
Max width of feeding |
350mm |
|
Max web diameter |
750mm |
|
Max web speed |
80m/min (speed varies by different material and patterns) |
|
Accuracy |
±0.1mm |
|
Dimensions |
L 7140×W 2000×H 1820 mm |
|
Weight |
3000KG |
|
Power supply |
380V 3 phases 50/60HZ |
|
Air pressure |
＞0.4mpa |
|
Laser power |
200W |
|
Water chiller power |
1.2KW-3KW |
|
Exhaust system power |
1.2KW-3KW |
